Features
・ Built-in remote Sensing circuit
・ Automatic zero function(Option)
・ CALIB. is equipped normally.
・CHECK is equipped normally
Specification
| Specification name | Specification contents |
|---|---|
| Bridge power supply | 10 VDC±0.3VDC within 120 mA (Changeable to 2.5 VDC or 5 VDC) with remote sensing function |
| Input range | 0.3 mV/V ~ 3 mV/V |
| Output | Output ±10 V (±0.3 mV/V input at bridge power supply DC10 V) |
| Output Load Resistance | 2 k-ohm or more |
| Zero adjustment range | ±2.4 mV/V |
| Non-linearity (Display and voltage output) |
0.01 %F.S. |
| Temperature efficient | Zero point within ±0.45 μV/℃ (Input conversion), Sensitivity within ±0.005 %F.S./℃ |
| Frequency response range | 10 Hz (Changeable to 1 Hz, 100 Hz) |
| Operating temp. / humidity range | Temperature -10 ℃~ 50 ℃, Humidity 80 %RH or less (Non condensing) |
| Power supply | Power supply voltage 100 VAC±10 VAC, 50/60 Hz, Power consumption Approx.10 VA (at 100 VAC) |
| Outline dimensions (WxHxD) | 42 mm x 176 mm x 164.4mm (Excludes protruding parts) |
| Weight | Approx. 1.5 kg |
Download
Options
- Current output
- Automatic zero function
- Power supply voltage
