M1G10

Click the arrow icon in the table below to switch from ascending to descending order.

scroll

Model	Rated Voltage [V]	No load speed [min-1]	No Load Current [mA]	Rated Load [gf･cm]	Rated Load [mN・m]	Rated Load Speed [min-1]	Rated Load Current [mA]	Max Rated Load Torque [gf･cm]	Max Rated Load Torque [mN・m]	Starting Torque [gf･cm]	Starting Torque [mN・m]	Gear Ratio	Weight [g]
M1G10FB10NB	5.0	695	36.0	51.00	5.00	567	138	92.500	9.1	278.00	27.00	1:19	13.0
M1G10FB10NF	5.0	129	36.0	153.00	15.00	114	100	255.000	25.0	1348.00	132.00	1:102	13.0
M1G10FB10NK	5.0	44	36.0	153.00	15.00	42	60	255.000	25.0	3520.00	345.00	1:298	13.0

The final appearance shape and characteristics need to be discussed.
