M1G6

Click the arrow icon in the table below to switch from ascending to descending order.

scroll

Model	Rated Voltage [V]	No load speed [min-1]	No Load Current [mA]	Rated Load [gf･cm]	Rated Load [mN・m]	Rated Load Speed [min-1]	Rated Load Current [mA]	Max Rated Load Torque [gf･cm]	Max Rated Load Torque [mN・m]	Starting Torque [gf･cm]	Starting Torque [mN・m]	Gear Ratio	Weight [g]
M1G6FB08AB	5.0	736	38.0	20.00	2.00	635	82	49.600	4.9	149.00	15.00	1:19	11.0
M1G6FB08AF	5.0	137	38.0	102.00	10.00	118	84	24.800	23.6	722.00	71.00	1:102	11.0
M1G6FB08AK	5.0	47	38.0	153.00	15.00	43	65	255.000	25.0	1888.00	185.00	1:298	11.0

The final appearance shape and characteristics need to be discussed.
