SG24P

Click the arrow icon in the table below to switch from ascending to descending order.

scroll

Model	Rated Voltage [V]	No load speed [min-1]	No Load Current [mA]	Rated Load [gf･cm]	Rated Load [mN・m]	Rated Load Speed [min-1]	Rated Load Current [mA]	Max Rated Load Torque [gf･cm]	Max Rated Load Torque [mN・m]	Starting Torque [gf･cm]	Starting Torque [mN・m]	Gear Ratio	Gear Step	Gear Box L1 [mm]	Weight [g]
SG24P1JTC	12.0	96	64.0	408.00	40.00	87	125	2243.000	220.0	4486.00	440.00	1:16	2	29.8	171.4
SG24P2NTC	12.0	94	257.0	7653.00	750.00	83	1208	25492.000	2500.0	66281.00	6500.00	1:64	3	38.3	201.0

The final appearance shape and characteristics need to be discussed.
Depending on the required quantities, it might be difficult to accept the request.
